TREND RS/JIG ROUTER SURFACING JIG

Ref: RS/JIG
new
Feefo logo
Delivery Next day delivery available on this item
The Trend RS/JIG Routing Surfacing Jig is an adaptable, compact jig for flattening, surfacing and trenching work on wide or irregular shaped material. More
£118.80 inc. VAT
(£99.00 exc. VAT)
  • TREND RS/JIG ROUTER SURFACING JIG

    + FREE Trend Stealth Mask worth £22.80! For a limited time only, while stocks last

    • Ideal for wider materials - Surfaces and flattens stock up to 400mm wide
    • End grain routing - Routing cut across the surface of end grain for clean finish
    • Controlled cutting - Depth of cut can be easily controlled with the router plunge for fine skimming cuts or deeper levelling cuts
    • Bi-directional cutting - Can be used across or along the grain
    • HPL material - High Pressure Laminate running rails and router cradle for wear-free performance, accuracy and durability
    • Twin 12mm stainless steel rails - Supports heavier routers up to 7Kg weight without distortion
    • Fixed position cradle - Cradle can be locked to the bars for single axis movement such as trenching cuts
    • No fixed sub base required - Simple guide bush location cradle for fast set up and removal
    • 30mm guide bush connection - Links to the cradle with 30mm guide bush for compatibility with multiple brands and router sizes
    • Extendable design - Additional running rails can be added for longer sleds
    • Slim modular design - Easily stores away saving workshop space

    Internal code: TP260875

  • TREND RS/JIG ROUTER SURFACING JIG

    Rails

    • Length: 511 mm
    • Width: 50 mm
    • Thickness: 12 mm

    Steel bars

    • Length: 511mm
    • Thickness: 12mm
    • Router base plate bore: 30 mm
    • Max. router weight: 7 kg
  • TREND RS/JIG ROUTER SURFACING JIG

    • 4x Rails
    • 2x Steel bars
    • 1x Router base plate
    • 16x Fixing screws
